MICROWAVE THERAPY (Bernini Studio) |
|
 |
CERVICAL-BRACHIALGIAS; MUSCULAR CONTRACTURES; MUSCULAR CONTUSIONS; MUSCULAR STRAINS; SUBACUTE EPICONDYLITY; FIBROYALGIAS; ILLNESS OF RAYNAUD
BERNINI STUDIO is a mobile unit delivery therapeutic microwaves (Radar-therapy) for casualty professional applications.
BERNINI STUDIO is realized applying the most advanced electronic technologies; it has a high brightness graphic display (5” size) with adjustable contrast. The utility control is made through a knob and some keys or through an optional remote control.
BERNINI STUDIO includes the following parts: a movable cart containing the power generator, a panel in which are the interactive controls of the unit, an adjustable arm sustaining the irradiator.
BERNINI STUDIO is supplied with memorized protocols, and allows the storing of personalized protocols, and programs (up to 40). The programs memorization can be made by using the controls of the unit itself.
BERNINI STUDIO can work in continuous mode (variable modulation) or in impulsive mode (duty-cycle or number of variable impulse).
CHARACTERISTICS:
- High luminosity graphic display
- Controls of the unit made by one knob, keys or optional remote control
- Wide handle-bar to move the unit
- Whells with block-system
- More than 70 stored therapeutic protocols
- 240 customized programs
- Irradiators: circular-rectangular-tridimensional
- Working mode: continuous or impulse
- Repetition of impulses
- Automatic safety controls
|
|
| TECHNICAL CHARACTERISTICS |
| Mains Voltage |
230 Vac/ 50-60 Hz |
| Input Power |
500 VA |
| Treatment Time |
From up to 30 min. |
| Working Frequency |
2450 MHz (2,45 GHz) |
| Max Output Power |
250 W on 50 Ohm |
| Working Mode |
Continuous or Impulse |
| Modulation |
From 20 to 100% |
| Duty Cycle |
From 20 to 80% |
| Max Output Intensity |
3W/cm2 |
| Repetition of impulses |
From 1 to 4 |
| Electric Safety Class |
1 B |
| Size (W X H X D) |
620 X 1050 X 600 |
| Weight |
30 |
|
|
 |
|
|
| |
|
| |
